Sauna Type

Traditional Outdoor Sauna

Model

CU580

Collection

Pure Cube

Manufacturer

Dundalk LeisureCraft

Capacity

3–4 People

Sauna Volume

Approximately 286 cu. ft.

Installation Environment

Outdoor

Country of Manufacture

Canada

Exterior Depth

Approximately 94.5" / 240 cm

Exterior Width

Approximately 110.2" / 280 cm

Overall Width

Approximately 100"

Overall Depth

Approximately 68"

Overall Height

Approximately 91"

Nominal Sauna Size

5' × 8'

Exterior Wood

Clear Western Red Cedar

Roof

Waterproof EPDM Membrane

Roof Design

Flat Profile with Rear Overhang

Interior Wood

Clear Western Red Cedar

Seating

Two-Tier Bench System

Bench Design

Fully Enclosed with Rounded Front Corners

Backrest

Integrated Cedar Backrest

Floor

Full Cedar Floor

Capacity

Designed for 3–4 Adults

Door Location

Side Wall

Door Orientation

Left- or Right-Side Configuration Available

Primary Wood

Clear Western Red Cedar

Wood Sourcing

Sustainably Harvested Canadian Western Red Cedar

Wall Construction

Prefabricated Cedar Wall Panels

Roof Construction

Prefabricated Roof Panels

Floor Construction

Full Cedar Floor System

Corner Construction

Cedar Corner Posts & Trim

Door Hinges

Stainless Steel

Roof Membrane

Waterproof EPDM

Interior Finish

Natural Cedar

Front Glazing

Three Large Glass Panels

Window Glass

5 mm Bronze Tempered Glass

Sauna Door

10 mm Bronze Tempered Glass

Privacy Option

Semi-Privacy Cedar Screens Available

Semi-Privacy Design

Fixed Exterior Cedar Grilles over Glazing

Heater

Saunum Air Perfect 7

Heating Type

Traditional Electric Sauna Heater with Integrated Air-Climate System

Heating Power

6.9 kW / 6,900W

Recommended Sauna Volume

210–350 cu. ft.

CU580 Sauna Volume

Approximately 286 cu. ft.

Heat Distribution

Saunum Patented Air-Blending System

Air Circulation

Integrated Fan-Assisted Climate System

Steam / Löyly

Water May Be Applied to Sauna Stones

Heater Construction

AISI 316 Stainless Steel + Magnelis® Coating

Himalayan Salt Spheres

Included

Control System

Saunum AirIQ Wi-Fi

Control Interface

Digital Touchscreen

Wi-Fi Connectivity

Included

Remote Operation

Saunum Mobile App

Mobile Compatibility

iOS + Android

Temperature Control

Digital

Fan Control

Integrated Climate-System Control

Scheduling

Remote Sauna Scheduling Available

In-Sauna Fan Control

Compatible with Saunum Fan Button

Voltage

240V

Phase

Single Phase

Heater Power

6.9 kW / 6,900W

Dedicated Circuit

Required

Circuit Breaker

40A

Supply Conductor

#8 Copper

Electrical Connection

Hardwired

Installation

Licensed Electrician Required

Final Installation

Must Comply with Saunum Requirements, NEC & Applicable Local Electrical Codes

Interior Lighting

Optional Sauna Lighting

Interior / Exterior Lighting

Available

Light Shade

Cedar Light Shade Available

Smart Control

Saunum AirIQ Wi-Fi

Mobile Control

Saunum App

Climate Technology

Saunum Air Perfect Air-Blending System

Ventilation Type

Passive Adjustable Ventilation

Vent System

Dual-Vent System

Fresh-Air Intake

Low-Level Intake Positioned Beneath Heater

Exhaust Vent

High-Level Outlet Positioned Opposite Heater

Vent Control

Adjustable Interior Cedar Vent Cover

Air-Climate System

Saunum Air Perfect 7 Integrated Air-Blending Technology

Active Air Circulation

Fan-Assisted Internal Air Blending

Heat Distribution

Blends Hot Upper-Level Air with Cooler Lower-Level Air for More Even Temperature Distribution

Post-Session Ventilation

Supports Air Circulation & Interior Drying

Delivery Configuration

Prefabricated Sauna Kit

Wall Construction

Preassembled Wall Panels

Roof Construction

Three Prefabricated Roof Panels

Floor

Full Cedar Floor Assembly

Foundation

Level, Solid Base Required

On-Site Assembly

Required

Heater Installation

Professional Installation Required

Electrical Connection

Licensed Electrician Required

Site Preparation

Determined by Installation Location & Local Requirements

MERIDIAN Coordination

Site preparation, delivery, professional assembly, electrical preparation, heater installation and final project coordination available through The MERIDIAN Experience.

Sauna Manufacturer Warranty

5-Year Limited Residential Warranty

Coverage

Defects in Materials & Workmanship Under Normal Residential Use

Saunum Air Perfect 7 — Residential

2 Years

Saunum Air Perfect 7 — Commercial

1 Year

AirIQ Wi-Fi

Covered Under Applicable Saunum Equipment Warranty

Installed Equipment

Subject to the Applicable Equipment Manufacturer's Warranty

Warranty Eligibility

Proper Installation, Operation & Maintenance Required

Exclusions

Normal Wear, Improper Installation, Misuse, Insufficient Maintenance & Conditions Outside Manufacturer Coverag

Sauna Manufacturer

Dundalk LeisureCraft Inc.

Country of Manufacture

Canada

Sauna Structure

No Independent UL, ETL or CSA Certification Published for the CU580 Structure

Heating Equipment

Saunum Air Perfect 7 — North American 240V Configuration

Control System

Saunum AirIQ Wi-Fi — North American Configuration

Electrical Installation

Must Comply with Saunum Requirements, NEC & Applicable Local Electrical Codes

Final Compliance

Subject to Installed Equipment & Installation Jurisdiction
