Model: Barracuda X2
Product Type: Integrated Hot + Cold Immersion System
Configuration: Horizontal Full-Body Plunge
User Capacity: One Adult
Installation: Freestanding
Available Finishes: Black or White Premium Powder-Coated Finish

Exterior Length: 82.7"
Exterior Width: 31.5"
Exterior Height: 38"

Internal Tank Length: 45.7"
Internal Tank Width: 27.4"
Internal Tank Depth: 35.4"

Listed Product Weight: Approximately 553 lb
Shipping Dimensions: Approximately 85"L × 34"W × 53"H
Listed Shipping Weight: Approximately 773 lb

Immersion Tank: Heavy-Duty Stainless Steel
Tank Construction: Insulated
Exterior Structure: Durable Metal Enclosure
Exterior Finish: Premium Powder-Coated Finish
Surface Material: Non-Slip Marine-Grade Foam
Wood Construction: None on Updated Model
Equipment Configuration: Fully Enclosed Plumbing, Electrical and Mechanical Systems
Equipment Access: Three Lockable Access Panels
Mobility: Six Commercial Caster Wheels
Seat: Removable Internal Seat
Cover: Insulated Foam Cover Included
Interior Lighting: Underwater LED Light System

Function: Active Cooling + Heating
Temperature Range: 37°F–107°F / 3°C–42°C
Published Chiller Rating: 2.0 HP
Temperature Management: Automatic Start + Stop
Temperature Scheduling: Programmable
Remote Temperature Control: Yes
Cooling Rate: Dependent on starting water temperature, ambient temperature and installation conditions
Heating Rate: Dependent on starting water temperature, ambient temperature and installation conditions

Filtration: Commercial-Grade Dual Filtration System
Filter Rating: 20 Microns
Purification: Automatic Ozone Purification
Water Circulation: Continuous Integrated Circulation
Surface Cleaning: Integrated Surface-Level Water Skimmer
Flow Monitoring: Water-Flow Pressure Gauge
Water Shutoff: Multiple Integrated Shutoff Valves
Drain Connection: Flexible ¾" Threaded Drain Connection
Hose Protection: Semi-Insulated Hose Sleeves Designed to Reduce Condensation

On-Unit Control: Integrated Touchscreen Display
Connectivity: Wi-Fi
Mobile Control: Smartphone App
Remote Temperature Adjustment: Yes
Remote System Operation: Yes
Water-Flow Monitoring: Yes
Programmable Scheduling: Yes
Maintenance Scheduling: Yes
Automatic Temperature Maintenance: Yes

Voltage: 110–120V AC
Frequency: 60 Hz
Maximum Current: 18A
Connection: Cord-and-Plug Connection
Required Receptacle: Properly Grounded GFCI-Protected Outlet
Integrated Protection: Built-In GFI/GFCI Breaker
Dedicated Circuit: Recommended; final electrical requirements should be confirmed with Barracuda and a licensed electrician
Professional Electrical Installation: Recommended where a compliant receptacle is not already available

Placement: Solid, Level and Structurally Appropriate Surface
Filled-Weight Planning: Required before installation
Drainage: Access to an appropriate drainage location required
Water Supply: Hose or nearby water source required for filling
Service Clearance: Clearance must be maintained around lockable equipment-access panels
Ventilation: Adequate airflow must be maintained around the integrated heating and cooling system
Freeze Protection: Unit and plumbing must be protected from freezing conditions
Outdoor Installation: Site conditions, drainage, electrical protection and climate exposure must be reviewed before installation

• Stainless-steel insulated immersion tank
• Integrated 2.0 HP heating and cooling system
• Commercial-grade dual filtration
• Automatic ozone purification
• Surface-level water skimmer
• Water-flow pressure gauge
• Removable internal seat
• Underwater LED lighting
• Integrated touchscreen
• Wi-Fi and smartphone control
• Six commercial caster wheels
• Marine-grade non-slip foam surfaces
• Insulated foam cover
• Integrated drainage connection
• Fully enclosed mechanical equipment

Tub + Frame: 2-Year Limited Warranty
Chiller: 1-Year Limited Warranty

Warranty exclusions may include damage associated with neglected filter maintenance, freezing conditions, interrupted power, inadequate water flow, misuse or abuse. Final warranty coverage should be confirmed on the purchase agreement.
