Sauna Type

Traditional Outdoor Sauna

Capacity

3–4 People

Configuration

Sauna Room + Integrated Covered Terrace

Installation Environment

Outdoor / Year-Round Use

Construction

Ready-Made / Factory-Built Sauna House

Country of Manufacture

Estonia

Weight

Approximately 3,748 lbs. / 1,700 kg

Exterior Width

Approximately 110.2" / 280 cm

Exterior Depth

Approximately 94.5" / 240 cm

Exterior Height

Approximately 97.6" / 248 cm

Wall Thickness

Approximately 3.7" / 95 mm

Exterior Cladding

Thermo-Pine with Hidden Fasteners

Standard Exterior Finish

Black

Base Beams

Impregnated Wood

Roofing

Protan SE 1.2 mm PVC Roofing

Rain Management

Integrated Rainwater Gutter System

Seating

Upper & Lower Sauna Benches

Standard Bench Configuration

I-Shaped

Optional Bench Configuration

L-Shaped

Interior Cladding

Alder

Bench Material

Alder

Backrest

Alder

Bench Skirting

Alder

Floor Grate

Alder

Optional Interior

Thermo-Aspen

Terrace

Integrated Covered Outdoor Transition & Relaxation Area

Exterior Material

Thermo-Pine

Interior Material

Alder

Optional Interior Material

Thermo-Aspen

Insulation

Mineral Wool

Wall Construction

Approximately 95 mm Insulated Wall System

Vapor Barrier

Reflective Vapor-Barrier Membrane

Wind Barrier

Integrated Wind-Barrier Membrane

Base Structure

Impregnated Wood

Roof Material

UV- & Temperature-Resistant Protan SE PVC

Glazing Type

Double-Glazed Tempered Glass

Standard Glass Finish

Clear

Optional Glass Finishes

Gray or Bronze

Window Frames

Wood

Door

Self-Closing Glazed Door

Door Lock

Included

Door Handle

Natural Oak & Stainless Steel

Optional Additional Glazing

Vertical or Horizontal Side Window Available

Heater

Saunum Air Perfect 7

Heating Type

Traditional Electric Sauna Heater with Integrated Air-Climate System

Heating Power

6.9 kW / 6,900W

Recommended Sauna Volume

210–350 cu. ft.

Maximum Temperature

194°F

Heat Distribution

Saunum Patented Air-Blending System

Air Circulation

Integrated Fan-Assisted Climate System

Steam / Löyly

Water May Be Applied to Sauna Stones for Traditional Steam

Heater Construction

AISI 316 Stainless Steel + Magnelis® Coating

Himalayan Salt Spheres

Included

Control System

Saunum AirIQ Wi-Fi

Control Interface

Digital Touchscreen

Wi-Fi Connectivity

Included

Remote Operation

Saunum Mobile App

Temperature Range

104–194°F

Climate Control

Adjustable Air-Circulation Control

Scheduling

Remote Sauna Scheduling Available

Safety Features

Integrated Temperature Monitoring & Safety Controls

Voltage

240V

Phase

Single Phase

Heater Power

6.9 kW / 6,900W

Dedicated Circuit

Required

Circuit Breaker

40A

Supply Conductor

#8 Copper

Electrical Connection

Hardwired

Installation

Licensed Electrician Required

Final Installation

Must Comply with Saunum Requirements, NEC & Applicable Local Electrical Codes

Ventilation Type

Forced Mechanical Ventilation

Fresh-Air Exchange

Integrated

Air Exhaust

Integrated

Air-Climate System

Saunum Air Perfect Active Air-Blending Technology

Air Circulation

Fan-Assisted Air Circulation

Heat Distribution

Blends Hot Upper-Level Air with Cooler Lower-Level Air

Climate Performance

Designed to Create More Even Temperature & Steam Distribution

Moisture Management

Supports Post-Session Ventilation & Interior Drying

Floor Drain

Integrated

Interior Lighting

Integrated LED Lighting

Backrest Lighting

LED Lighting Behind Backrest

Under-Bench Lighting

Integrated LED Lighting

Exterior Lighting

Integrated Architectural LED Lighting

Lighting Control

Remote-Controlled / Dimmable Configuration Available

Smart Controls

Saunum AirIQ Wi-Fi

Mobile Control

Saunum App

Audio

Bluetooth Speaker System Available

Voltage

240V

Phase

Single Phase

Heater Power

6.9 kW / 6,900W

Dedicated Circuit

Required

Circuit Breaker

40A

Supply Conductor

#8 Copper

Electrical Connection

Hardwired

Installation

Licensed Electrician Required

Final Installation

Must Comply with Saunum Requirements, NEC & Applicable Local Electrical Codes

Ventilation Type

Mechanical / Forced Ventilation

Fresh-Air Exchange

Integrated

Air Exhaust

Integrated

Air-Climate System

Saunum Air Perfect Integrated Air-Blending Technology

Air Circulation

Active Fan-Assisted Air Circulation

Fan Control

Adjustable

Heat Distribution

Blends Hot Upper-Level Air with Cooler Lower-Level Air

Climate Performance

Designed to Create More Even Temperature & Steam Distribution

Moisture Management

Supports Post-Session Ventilation & Interior Drying

Delivery Configuration

Ready-Made / Factory-Built Sauna House

On-Site Structural Assembly

Not Required Under Normal Installation Conditions

Foundation

Stable, Level Structural Base Required

Placement

Heavy-Lifting Equipment / Crane May Be Required

Site Access

Must Accommodate Delivery & Final Placement

Electrical Preparation

Required

Heater Connection

Hardwired

Electrical Installation

Licensed Electrician Required

Drainage

Site Drainage Provisions May Be Required

Final Commissioning

Required Following Installation

MERIDIAN Coordination

Site preparation, delivery, placement, electrical preparation, installation and final project coordination available through The MERIDIAN Experience.

Saunum Equipment Warranty — Residential

2 Years

Saunum Equipment Warranty — Commercial

1 Year

AirIQ Wi-Fi Warranty — Residential

2 Years

Coverage

Manufacturing & Material Defects

Warranty Eligibility

Original Purchaser & Original Installation

Installation Requirement

Electrical Equipment Must Be Installed by a Licensed, Certified Electrician

Warranty Documentation

Completed Installation Report Required for Applicable Equipment Claims

Exclusions

Normal Wear, Routine Maintenance, Improper Installation, Misuse, Unauthorized Modification, Transport Damage & External Causes

Sauna Manufacturer

Saunum Group AS

Country of Manufacture

Estonia

Heater

Manufacturer

Saunum Group AS

Country of Manufacture

Estonia

Sauna Structure Certification

No Independent UL, ETL or CSA Certification Published for the AirCube Terrace Structure

Heating Equipment

Saunum Air Perfect 7 — North American 240V Configuration

Control System

Saunum AirIQ Wi-Fi — North American Configuration

Electrical Installation

Must Comply with Saunum Requirements, NEC & Applicable Local Electrical Codes

Final Compliance

Subject to Installed Equipment & Local Jurisdiction
